Teachers

GCSE AQA cold environments · 15 minutes · no login

Periglacial landforms

All teacher notes · Open the lab · 1677 words · ·

Field photograph or official scientific figure for teaching periglacial. A second photograph for the projector script — not the lab cover. Source: Wikimedia Commons / NASA / USGS / NOAA, public domain or CC.Wikimedia Commons / NASA / USGS / NOAA, public domain or CC

Why this lesson, and why the 3D

Periglacial landforms is a fifteen-minute projector lesson, not a homework packet and not a film with a quiz bolted on. Put this hook on the board before you dim the lights: The Cairngorms still carry freeze–thaw scars. Alaska still has ice wedges growing. Cold without a glacier is its own factory. By the end of the slot a pupil should be able to grow an ice wedge and patterned ground with freeze–thaw, and distinguish this machine from a glacier’s U-trough. Curriculum tags in the header (GCSE AQA cold environments; A-level glacial / periglacial) are filters, not a flag. The room is worldwide; SI first; International English. Ages on the card (GCSE, A-level, HS Earth Sci) are a suggested band, not a gate.

The Cairngorm plateau is a museum of freeze–thaw: blockfields, nivation hollows, soils that move when they thaw. Alaska’s coastal plain grows ice-wedge polygons you can see from the air. GCSE cold environments mix glacial and periglacial until students call every cold landform a glacier. This lab is the other machine. If they only remember U-troughs, they will misread a patterned-ground question and a Yorkshire-Dales limestone pavement alike — karst is yet another lab.

The 3D is a named, inspectable object. Click the part, not a caption. If the model will not spin, the Why panel still carries the mechanism, the two photographs, and the film. Do not apologise for the model. Drive it. A silent spin teaches a screensaver. A named mesh that changes under a slider teaches the process.

Fifteen minutes on the projector

A cold ground. No valley glacier on stage.\nAsk whether freeze–thaw can build landforms without ice flowing. Wait.\nRaise cycles. Ice wedges thicken. Polygons sort.\nCairngorms relict. Alaska live.\nA U-trough is the glacier lab. Do not steal it.\nCaption: ice is in the ground, and it has thickness.\nSpace, L, P. Then Check.

Open the lab full screen (F). Labels on (L). Speak the first step before you touch a slider: A cold ground, no ice sheet required. Then the second: Freeze–thaw opens a wedge. Patterned ground. Then the third: Not a U-trough. That is the glacier lab.

The sliders that earn their keep are Freeze–thaw. Space plays; arrows nudge time; R resets. Parameters the URL can remember: cycles. If you only have eight minutes, skip the last step and finish in Check. Projector layout (P) is for the back row: one idea, large type, the model still live.

Leave cycles low. A quiet ground. Raise freeze–thaw. Wedges thicken; polygons read. Keyboard: Space, arrows, L, R, P. Ask whether a glacier is required before you reveal the caption. Toggle labels on the wedge and the polygon, not on a U-trough.

The in-site film is “What Are Glaciers? Crash Course Geography #23” (Crash Course Geography, about 11 min, Crash Course / Complexly on YouTube. Standard YouTube licence. Educational embed, autoplay off.). Autoplay is off. Play one minute if you need a second voice; do not let the film eat the slot. The 3D still has to move under your hand.

What the third row will get wrong

You will hear the misconception before you have finished the first sentence. Write the false claim on the board and leave it there until the model has contradicted it. Do not skip this. A fluent pupil can recite the hook and still believe the false sentence.

“Every cold landform was carved by a glacier.” — no. Freeze–thaw in the ground is a different factory. Look for wedges and polygons, not a U-trough.

“Ice wedges are tiny rivers.” — no. They are cracks that freeze. Water is a filler, not a channel.

“The Cairngorms have no periglacial story because the ice has gone.” — no. Relict forms remain. Alaska is the live pair.

Pitfalls to keep in your pocket: All cold = glacial. Ice wedges as rivers. Relict Cairngorms treated as empty of this story. Do not let a pupil leave thinking the 3D is a photograph. It is a teaching model. Where vertical exaggeration exists, T collapses it and the caption says so. A labelled lie of scale is honest. An unlabelled one is a cartoon.

Two places, not a slogan

Input is freeze and thaw, again and again. Water in a crack expands when it freezes; the crack widens; summer melt lets more water in. Ice wedges grow. Stones are heaved and sorted into polygons and stripes. Nivation hollows deepen under lingering snow. What moves: ice in the crack, stones toward polygon edges. What does not: a valley glacier. What is conserved: the ground as the stage — this is not ice flowing downhill. The lie: neat hexagons, a single season on a slider. Real polygons take centuries. Real Cairngorms are relict in today’s milder climate; Alaska is live. Vertical exaggeration on the wedge so the back row can see thickness. The glacier lab’s ice has a tongue. This ice is in the ground.

The first place to land is Cairngorm freeze–thaw. The second is Alaska / high-Sierra cold ground. Same process, different rock or climate. If a pupil can only name one place, they have a postcard, not a mechanism. Atlas entries for those names are a click from the case list; send them back to the lab with one sentence they can say in Check.

Do not flatten the comparison into “this country versus that country.” Name the landform. Holderness is till, not chalk. Hawaii is a hotspot, not an island arc. Yosemite is a glacial trough, not a river canyon. The 3D is allowed to be schematic; the place names are not allowed to be sloppy.

Figures and the film

Field photograph: Patterned ground: polygons from freeze–thaw. Freeze–thaw without a glacier. Credit: USGS, public domain.

Mechanism photograph: Field photograph or official scientific figure for teaching periglacial. Field photograph or official scientific figure for teaching periglacial. A second photograph for the projector script — not the lab cover. Source: Wikimedia Commons / NASA / USGS / NOAA, public domain or CC. Credit: Wikimedia Commons / NASA / USGS / NOAA, public domain or CC.

Two photographs, two jobs. The field picture is the place. The mechanism picture is the process. Do not run the lesson on a single Apollo Earth disc. A carbon-cycle class is a forest and a seam, not a blue marble. An ENSO class is a Pacific temperature map, not Africa from Apollo 17.

Words they must be able to say

Say these out loud once while you click the matching mesh. If a word has no mesh, it still has a photograph in Terms.

Periglacial: Cold-climate processes at the ice margin, or in cold ground with no glacier. Ice wedge: A crack that fills and freezes, widening year on year. Patterned ground: Sorted stones in polygons or stripes from freeze–thaw heave. Nivation: Erosion under a lingering snow patch. A hollow, not a cirque on its own. Blockfield: A sheet of frost-shattered blocks on a plateau. Exam language also accepts “Felsenmeer”. Active layer: The top that thaws in summer over permafrost. Permafrost: Ground that stays frozen through the year. Not the same as a glacier.

Exam-language toggle (the Teacher tab) swaps UK/US pairs where they exist — levée/levee, arête/arete — so a mixed room is not punished for spelling.

Close the slot

Without the canvas: periglacial is cold-ground process without a glacier doing the carving. Freeze–thaw grows ice wedges and patterned ground. Cairngorms relict; Alaska live. A U-trough is the glacier lab. A clint-and-gryke pavement is karst. That is enough for Check.

Finish in Check — ten questions, not a mood. The bank mixes definition, process, the misconception you just killed, a named place, and a read-the-model item (click the part; T). If a pupil can only recite the hook, they have not used the geometry. Wrong answers still show the one-line explain. Do not skip the explain.

Sources on the Teacher tab are the trail, not a bibliography to copy. BGS periglacial; USGS / NSIDC permafrost.

Link back to the live lab and keep the same slug. Do not invent a parallel worksheet that contradicts T, SI, or the named parts.

This note is worldwide. Curriculum tags (GCSE AQA cold environments; A-level glacial / periglacial) are filters, not a flag. A class in Nairobi, London, or Shanghai can use the same 3D. Ages (GCSE, A-level, HS Earth Sci) are a suggested band. If a sentence only works in one exam board, rewrite it before you project it.

Write these three lines on the board before you dim the lights. One: The Cairngorms still carry freeze–thaw scars. Alaska still has ice wedges growing. Cold without a glacier is its own factory. Two: the misconception “Every cold landform was carved by a glacier.”. Three: the named parts they must click. Then drive the model. Check is ten questions covering definition, process, the misconception, a place, and a read-the-model item. Do not skip the explain on a wrong answer.

Board, units, and what not to say

SI first. Metres, kilometres, degrees Celsius, metres per second. A conversion in brackets is courtesy, not a second system. Do not let a pupil leave thinking the 3D is a photograph. It is a teaching model. Where vertical exaggeration exists, T collapses it and the caption says so.

Do not say “teaching mesh”, “sprinkle”, or “thin free surface not a fat pipe” out loud. Say the landform. Seasons are ~23.44° of axial tilt, not Earth–Sun distance. The outer core is liquid; S-waves do not pass. Yosemite is a glacial U-trough. San Andreas is a transform. Hawaiʻi and Yellowstone are hotspots. Florida is not a glacial trough.

If the room is noisy, projector layout (P) is the back-row setting: one idea, large type, the model still live. Full screen (F). Labels (L). Space plays. Arrows nudge time. R resets. The URL can remember cycles. Send them home with the same link; there is no login.

In-site film

What Are Glaciers? Crash Course Geography #23. Crash Course Geography. Crash Course / Complexly on YouTube. Standard YouTube licence. Educational embed, autoplay off. Autoplay off.
