Rain shadow

All teacher notes · Open the lab · 1736 words · ·

Why this lesson, and why the 3D

Rain shadow is a fifteen-minute projector lesson, not a homework packet and not a film with a quiz bolted on. Put this hook on the board before you dim the lights: The Lake District is wet on the west. Penrith, just over the ridge, is drier. The mountain is a barrier, not a cloud factory. By the end of the slot a pupil should be able to lift moist air over a ridge, watch it cool and drop rain windward, and say why the leeward slope is dry. Curriculum tags in the header (GCSE AQA 3.1.2; NGSS MS-ESS2-4; APES 4.8) are filters, not a flag. The room is worldwide; SI first; International English. Ages on the card (KS3, GCSE, NGSS MS, APES) are a suggested band, not a gate.

Keswick is wet. Penrith, over the Helvellyn ridge, is drier. The Lake District is a barrier in the westerlies, not a magic cloud. The Sierra Nevada does the same job at a continental scale: California’s Central Valley and the Owens Valley sit in the lee. GCSE weather and APES 4.8 both want orographic lift as a 3D machine, not a textbook cross-section you cannot turn. If a class thinks mountains ‘make rain’, they will not understand a desert next door.

The 3D is a named, inspectable object. Click the part, not a caption. If the model will not spin, the Why panel still carries the mechanism, the two photographs, and the film. Do not apologise for the model. Drive it. A silent spin teaches a screensaver. A named mesh that changes under a slider teaches the process.

Fifteen minutes on the projector

Point at moist air hitting the ridge. Do not name places yet.\nAsk where the rain will fall. Wait.\nRaise the barrier. Windward cloud. Lee dries.\nKeswick wet, Penrith drier. Same air.\nSierra Nevada, then Owens Valley. Same machine, bigger ridge.\nMountains do not make rain from nothing.\nSpace, L, P. Then Check.

Open the lab full screen (F). Labels on (L). Speak the first step before you touch a slider: Moist air hits the ridge. Then the second: Raise the barrier. Windward rain, leeward dry. Then the third: Sierra Nevada is the same machine at a larger scale.

The sliders that earn their keep are Ridge height; Moist wind. Space plays; arrows nudge time; R resets. Parameters the URL can remember: ridge, wind. If you only have eight minutes, skip the last step and finish in Check. Projector layout (P) is for the back row: one idea, large type, the model still live.

Point at the windward cloud before any place names. Raise Ridge height. Watch the lee dry. Keyboard: Space, L, R, P. The wind slider is optional weather; the ridge is the plot. Name Keswick then Penrith, then Sierra then Owens, after the air has moved.

The in-site film is “How Can Rain Create Conflict? Crash Course Geography #11” (Crash Course Geography, about 11 min, Crash Course / Complexly on YouTube. Standard YouTube licence. Educational embed, autoplay off.). Autoplay is off. Play one minute if you need a second voice; do not let the film eat the slot. The 3D still has to move under your hand.

What the third row will get wrong

You will hear the misconception before you have finished the first sentence. Write the false claim on the board and leave it there until the model has contradicted it. Do not skip this. A fluent pupil can recite the hook and still believe the false sentence.

“Mountains make rain.” — no. Mountains force air up. The water was already in the air.

“The desert next door means the mountain is in a different climate belt.” — no. Often it is the same air, after the rain fell.

“Leeward slopes are wet because clouds spill over.” — no. Descent warms and dries. Spillover happens; it is not the shadow.

Pitfalls to keep in your pocket: Mountains as cloud factories. Confusing rain shadow with latitude belts. Calling every dry valley a desert climate type. Do not let a pupil leave thinking the 3D is a photograph. It is a teaching model. Where vertical exaggeration exists, T collapses it and the caption says so. A labelled lie of scale is honest. An unlabelled one is a cartoon.

Two places, not a slogan

Input is moist air forced up. As the parcel rises it expands and cools. Relative humidity climbs; cloud and rain on the windward face. Over the crest the air descends, compresses, warms, and dries. That is the rain shadow. What moves: the parcel, the cloud, the rain streaks. What does not: the ridge, until you raise it. What is conserved: water in the parcel until it rains out. The lie: a single ridge, a single wind, no season. Real Lake District weather has fronts as well. Real Sierra has a rain shadow and a seasonal snowpack. This lab isolates the barrier. Coriolis is not invited. The three-cell lab is the planetary machine; this is the hill in the way.

The first place to land is Lake District west vs Penrith. The second is Sierra / Owens rain shadow. Same process, different rock or climate. If a pupil can only name one place, they have a postcard, not a mechanism. Atlas entries for those names are a click from the case list; send them back to the lab with one sentence they can say in Check.

Do not flatten the comparison into “this country versus that country.” Name the landform. Holderness is till, not chalk. Hawaii is a hotspot, not an island arc. Yosemite is a glacial trough, not a river canyon. The 3D is allowed to be schematic; the place names are not allowed to be sloppy.

Figures and the film

Field photograph: A dry basin in a rain shadow. Windward wet, lee dry. Credit: NPS / public domain.

Mechanism photograph: Field photograph or official scientific figure for teaching rain shadow. Field photograph or official scientific figure for teaching rain shadow. A second photograph for the projector script — not the lab cover. Source: Wikimedia Commons / NASA / USGS / NOAA, public domain or CC. Credit: Wikimedia Commons / NASA / USGS / NOAA, public domain or CC.

Two photographs, two jobs. The field picture is the place. The mechanism picture is the process. Do not run the lesson on a single Apollo Earth disc. A carbon-cycle class is a forest and a seam, not a blue marble. An ENSO class is a Pacific temperature map, not Africa from Apollo 17.

Words they must be able to say

Say these out loud once while you click the matching mesh. If a word has no mesh, it still has a photograph in Terms.

Orographic rainfall: Rain forced by air rising over high ground. Rain shadow: Dry region leeward of a barrier, after the air has already dropped water. Windward: The upslope side that faces the incoming moist air. Leeward: The downslope side. Air descends, warms, dries. Exam language also accepts “Lee”. Adiabatic cooling: A rising parcel expands and cools without heat being taken out by a fridge. School mechanism for cloud on the upslope. Föhn / chinook: Warm dry descent on the lee. A named wind, same machine. Barrier: The ridge that forces the lift. Height matters. Geology of the rock does not, in this lab.

Exam-language toggle (the Teacher tab) swaps UK/US pairs where they exist — levée/levee, arête/arete — so a mixed room is not punished for spelling.

Close the slot

Without WebGL: moist air rises, cools, rains on the windward slope, then descends dry. That is a rain shadow. Lake District west versus Penrith. Sierra Nevada versus Owens Valley. Mountains do not make rain from nothing; they force air up. A taller ridge is a sharper shadow. That is enough for Check.

Finish in Check — ten questions, not a mood. The bank mixes definition, process, the misconception you just killed, a named place, and a read-the-model item (click the part; T). If a pupil can only recite the hook, they have not used the geometry. Wrong answers still show the one-line explain. Do not skip the explain.

Sources on the Teacher tab are the trail, not a bibliography to copy. Met Office orographic rain; NOAA / WRCC Sierra precipitation.

Link back to the live lab and keep the same slug. Do not invent a parallel worksheet that contradicts T, SI, or the named parts.

This note is worldwide. Curriculum tags (GCSE AQA 3.1.2; NGSS MS-ESS2-4; APES 4.8) are filters, not a flag. A class in Nairobi, London, or Shanghai can use the same 3D. Ages (KS3, GCSE, NGSS MS, APES) are a suggested band. If a sentence only works in one exam board, rewrite it before you project it.

Write these three lines on the board before you dim the lights. One: The Lake District is wet on the west. Penrith, just over the ridge, is drier. The mountain is a barrier, not a cloud factory. Two: the misconception “Mountains make rain.”. Three: the named parts they must click. Then drive the model. Check is ten questions covering definition, process, the misconception, a place, and a read-the-model item. Do not skip the explain on a wrong answer.

Board, units, and what not to say

SI first. Metres, kilometres, degrees Celsius, metres per second. A conversion in brackets is courtesy, not a second system. Do not let a pupil leave thinking the 3D is a photograph. It is a teaching model. Where vertical exaggeration exists, T collapses it and the caption says so.

Do not say “teaching mesh”, “sprinkle”, or “thin free surface not a fat pipe” out loud. Say the landform. Seasons are ~23.44° of axial tilt, not Earth–Sun distance. The outer core is liquid; S-waves do not pass. Yosemite is a glacial U-trough. San Andreas is a transform. Hawaiʻi and Yellowstone are hotspots. Florida is not a glacial trough.

If the room is noisy, projector layout (P) is the back-row setting: one idea, large type, the model still live. Full screen (F). Labels (L). Space plays. Arrows nudge time. R resets. The URL can remember ridge, wind. Send them home with the same link; there is no login.

In-site film

How Can Rain Create Conflict? Crash Course Geography #11. Crash Course Geography. Crash Course / Complexly on YouTube. Standard YouTube licence. Educational embed, autoplay off. Autoplay off.
